Description

Durable LED bulkhead light for versatile use

This LED bulkhead round light gives you a reliable and energy-efficient solution with up to 1220 lumens of bright output. You can easily switch between 3000K and 4000K color temperatures, and its IK10 impact protection ensures durability in demanding environments. Perfect for corridors, stairwells, and entrance areas.

Key product benefits

You get a multi-lumen, switchable CCT design that provides flexibility for different spaces. Its 15,000-hour minimum lifespan and up to 50,000 on/off cycles make it a long-lasting choice. With CRI 80+ color quality, it delivers natural illumination while saving energy.

Main technical features

  • LED bulkhead round 250P with 10.5W power use offers strong efficiency and long-lasting performance.
  • Luminous output up to 1220 lumens ensures bright and practical lighting in everyday spaces.
  • Switchable 3000K/4000K CCT allows you to choose warm or neutral white light as needed.
  • IK10 impact rating provides excellent resistance against shocks and vandalism.
  • Constructed with durable White aluminum housing for a clean look and robust design.
  • CRI 80-89 ensures good color rendering for natural and accurate light.
  • Operates on 220-240V AC, compatible with standard electrical networks (50-60 Hz).
  • Tested to L70 B50 at 75,000 hours, meaning consistent light quality over time.

Where to use this LED bulkhead

This LED bulkhead light is ideal for public staircases, hallways, garages, outdoor covered areas, and offices. Thanks to its robust IK10 protection, it is also well-suited for locations where impact resistance is important.

Specifications

General

Product Name
BLKH RD 250 P 9.5W ML 83040 WT
Product Type
Bulkhead Round Luminaire
Description
Robust wall and ceiling luminaire with selectable color temperature and power.
Key Features
Selectable CCT and power steps (Multi Color / Multi Lumen)Suitable for dusty and damp locationsHigh impact resistanceDC capable for emergency lighting systemsThrough-wiring possible
Added Functions
EVERLOOP / MULTI SELECT

Electrical Ratings

Nominal Voltage
220-240 V
Mains Frequency
50/60 Hz
Selectable Power
9.5 W / 8 W / 6.5 W / 5.5 W
Selectable Nominal Current
42-25 mA
Power Factor
> 0.80
Total Harmonic Distortion
< 15%
Inrush Current
3.44 A
Inrush Current Time (Th50)
3.284 µs
Protection Class
II
Operating Mode
Integrated LED driver
Circuit Breaker Load
Max Luminaires per B16 Breaker
248
Max Luminaires per C10 Breaker
155
Max Luminaires per C16 Breaker
248

Control Gear

Selectable Output Current
350 mA / 300 mA / 250 mA / 200 mA
Output Ripple Current
< 5%

Photometrical Data

Selectable Luminous Flux
1220 lm / 1070 lm / 860 lm / 710 lm
Selectable Luminous Efficacy
120-132 lm/W
Selectable Color Temperature
3000 K / 4000 K
Light Color Designation
Warm White / Cool White
Color Rendering Index (CRI)
> 80
Standard Deviation of Color Matching
5 sdcm
Beam Angle
120°
Low Flicker
Yes
Flickering Metric (Pst LM)
< 1
Stroboscope Effect Metric (SVM)
< 0.4
Photobiological Safety Group
RG0

Physical Attributes

Product Color
White
Housing Color
White
RAL Color
RAL 9003
Housing Material
Polycarbonate (PC)
Cover Material
Polycarbonate (PC)
Light Emitting Surface Material
Polycarbonate (PC)
Mercury Content
0.0 mg
Dimensions
Diameter
262.0 mm
Height
73.0 mm
Product Weight
680.0 g

Durability and Environment

IP Rating
IP65
IK Rating (Impact Resistance)
IK10
Ambient Temperature Range
-20 to +40 °C
Storage Temperature Range
-20 to +80 °C
Glow Wire Test Temperature
850 °C

Lifespan

L70/B50 at 25°C
70000 h
L80/B10 at 25°C
55000 h
L80/B50 at 25°C
65000 h
L90/B10 at 25°C
40000 h
Number of Switching Cycles
100000

Installation and Features

Mounting Type
Surface
Mounting Location
Ceiling / Wall
Application Environment
Outdoor
Connection Type
Screwless push wire terminal
Dimmable
No
Light Source Included
Yes
Replaceable Light Source
Yes
EPREL Replaceable Source
Not replaceable

Emergency Lighting

Capability
EL certified driver (DC operation) for central battery operation included
Emergency Mode Power
9.5 W
Emergency Mode Luminous Flux
1220 lm
Emergency Operation Test Type
None

Certifications and Standards

Standards
CE, CB, UKCA, EAC, ENEC, EL, EPD
Limited Surface Temperature (D sign)
No
Ball Shot Safe
No
EPD Number
LEDV-00029-V01.01-EN

Logistical Data

Single Unit (Folding Box)
Product Code
4099854286100
Pieces per Unit
1
Dimensions (L x W x H)
77 mm x 266 mm x 266 mm
Gross Weight
783.0 g
Volume
5.45 dm³
Case (Shipping Box)
Product Code
4099854286117
Pieces per Unit
8
Dimensions (L x W x H)
545 mm x 280 mm x 335 mm
Gross Weight
6814.0 g
Volume
51.12 dm³
